Winzer

12 Volt Dc 20 Amp 4-Positions Dpst On/Off 4-Blades Terminal Heavy Duty Toggle Switch

Item 777.1.16

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

A DPST (double pole single throw) switch has two closed contact positions energizing two circuits at the same time. the circuits must be from separate sources. Because it is single throw it has one ON position an OFF-ON switch.

  • Plastic housing with plated steel cap
  • Nickel plated brass stem and mounting hardware
  • Mounting stem 15/32”-32 thd. 15/32” (11.90mm) long with keyway
  • Nickle plated brass handles 11/16” (17.46mm) long except for 777.1.2 which has a 1 - 1/2” handle
  • Fits panels up to 1/4” (6.35mm) thick.
  • Silver contacts for dependable electrical operations
  • 12V (DC) - 25 amps lamp load
  • 12V (dc) - 35 amps inductive load
  • 125V (AC) - 15 amps
  • 250V (AC) - 10 amps
