Winzer

12 Volt Dc 20 Amp 6-Positions Dpdt On/Off 6-Blades Terminal Heavy Duty Toggle Switch

Item 777.1.26

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

A DPDT (double pole double throw) switch has two closed contact positions energizing two separate circuits at the same time. Because it is double throw it has two ON positions an ON-OFF-ON or ON-ON switch.

  • Plastic housing with plated steel cap
  • Nickel plated brass stem and mounting hardware
  • Mounting stem 15/32”-32 thd. 15/32” (11.90mm) long with keyway
  • Nickle plated brass handles 11/16” (17.46mm) long except for 777.1.2 which has a 1 - 1/2” handle
  • Fits panels up to 1/4” (6.35mm) thick.
  • Silver contacts for dependable electrical operations
  • 12V (DC) - 25 amps lamp load
  • 12V (dc) - 35 amps inductive load
  • 125V (AC) - 15 amps
  • 250V (AC) - 10 amps

Photographs are representational and may not be size accurate.
