Winzer

#14-10 x 2 Inch Plain 316 (A4) Stainless Steel Flat - Countersunk Head Type-A Self-Tapping Sheet Metal Screw

Item 225.01.14.2

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

These machine screws have deeply sunk heads with flat top surfaces for fastening flatly against sides of metal joints and equipment. These screws sit flush against the surface of panels and electrical components for a finished look.

  • Origin: Imported
  • Diameter: #14
  • Drive Size: #3
  • Drive Type: Phillips
  • Finish: Plain
  • Head Diameter: 0.437 - 0.477 Inch
  • Head Height: 0.110 Inch
  • Head Style: Flat - Countersunk
  • Industry Standard: ASME/ANSI B18.6.4 SAE J78
  • Item: Self-Tapping Sheet Metal Screw
  • Length: 2 Inch
  • Material: 316 (A4) Stainless Steel
  • Measurement: Inch
  • Origin: Imported
  • Point Type: Type-A
  • Recess Diameter: 0.276 Inch
  • Recess Penetration Gagging Depth: 1/4 FPT x 1/4 MPT
  • Specification: ASME/ANSI B18.6.4 SAE J78
  • Threads Per Inch: 10
  • Type: Full Threaded

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #14
Drive Type Phillips
Head Style Flat
Length 2 Inch
Material 18-8 Stainless Steel
Measurement Inch
Point Type Type A
