Photographs are representational and may not be size accurate.

Winzer

18 Gauge 5/8 Inch X 1 Inch Astm F844 Clear Zinc Carbon Steel Narrow Rim Machine Bushing

Item 496.18.03

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

Hardness RC 30 max. Machine bushings are made of rugged carbon steel for maximum corrosion resistance Installed axially these round shims are used to take up slack on shafts Typical applications include industrial and farm machinery electronic equipment and power transmission assemblies Finish: Zinc Industry Standard: ASTM F844 Inside Diameter: 5/8 Inch Inside Diameter Maximum: 0.650 Inch Inside Diameter Minimum: 0.635 Inch Item: Machine Bushing Material: Carbon Steel Measurement: Inch Origin: Imported Outside Diameter: 1 Inch Outside Diameter Maximum: 1.010 Inch Outside Diameter Minimum: 0.993 Inch Specification: ASTM F844 Thickness: 18 Gauge Thickness Maximum: 0.054 Inch Thickness Minimum: 0.042 Inch Type: Narrow Rim

  • Hardness RC 30 max.
  • Machine bushings are made of rugged carbon steel for maximum corrosion resistance
  • Installed axially these round shims are used to take up slack on shafts
  • Typical applications include industrial and farm machinery electronic equipment and power transmission assemblies
  • Industry Standard: ASTM F844
  • Inside Diameter: 5/8 Inch
  • Inside Diameter Maximum: 0.650 Inch
  • Inside Diameter Minimum: 0.635 Inch
  • Item: Machine Bushing
  • Material: Carbon Steel
  • Measurement: Inch
  • Origin: Imported
  • Outside Diameter: 1 Inch
  • Outside Diameter Maximum: 1.010 Inch
  • Outside Diameter Minimum: 0.993 Inch
  • Specification: ASTM F844
  • Thickness: 18 Gauge
  • Thickness Maximum: 0.054 Inch
  • Thickness Minimum: 0.042 Inch
  • Type: Narrow Rim

Photographs are representational and may not be size accurate.

Key Specifications
Diameter 5/8 Inch
Finish Zinc
Material Carbon Steel
Measurement Inch
Retainer Type Narrow Machine Bushing
