Winzer

3/8 Inch Male JIC 37 Degree To M16 Banjo Steel Hydraulic Adapter

Item 680.35.616

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

The steel adapters are designed with good vibration resistance which decreases with increase in tube size.

  • Zinc plated broad selection of styles and sizes interchangeable with all sources
  • For hydraulic instrumentation and chemical processing systems
  • F1 (JIC) = 9/16-18
  • F2 (Metric) = 16X1.5
  • L = 30.0 mm
  • H = 18.0 mm
  • W = 28.00 mm
  • B Bore (Minimum) = 7.00 mm
  • T Thickness = 6.00 mm
  • Material Spec = Steel
  • Plating = ASTM B633-Fe/Zn 8-12
  • Relevant Standards = SAE J514 / ISO 8434-2 ISO 9974 / ISO 6149 / DIN 7631

Photographs are representational and may not be size accurate.

Key Specifications
Pipe Size 3/8 Inch
Diameter M16
Material Steel
