Winzer

#4-24 x 1/2 Inch Plain 18-8 (A2) Stainless Steel Pan Head Type-A Self-Tapping Sheet Metal Screw

Item 118.4.12

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

Pan head design is slightly rounded with minimal vertical sides. Square drive is designed to reduce the risk of stripping and allow single-handed installation. Additionally reduces the ability to tamper with the fastener once installed.

  • Origin: Imported
  • Pan Head Style: For general applications
  • Can be substituted in most applications for round truss or binding heads
  • Phillips Drive: Most recommended drive type Provides good control in driving
  • Always use a driver bit of the proper size which is in good condition
  • Drive Size: #1
  • Drive Type: Phillips
  • Finish: Plain
  • Head Diameter: 0.205 - 0.219 Inch
  • Head Height: 0.058 - 0.068 Inch
  • Head Style: Pan
  • Industry Standard: ASME/ANSI B18.6.4 SAE J78
  • Item: Self-Tapping Sheet Metal Screw
  • Length: 1/2 Inch
  • Material: 18-8 (A2) Stainless Steel
  • Measurement: Inch
  • Origin: Imported
  • Point Type: Type-A
  • Recess Diameter: 0.115 Inch
  • Recess Penetration Gagging Depth: 0.053 - 0.071 Inch
  • Specification: ASME/ANSI B18.6.4 SAE J78
  • Threads Per Inch: 24

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #4
Drive Type Phillips
Head Style Pan
Length 1/2 Inch
Material 18-8 Stainless Steel
Measurement Inch
Point Type Type A
