Winzer

#8-15 x 1 Inch Polor White Powder Coated Type A Square Drive Pan Head Self-Tapping Sheet Metal Screw

Item 110.9.8.1

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

Pan head design is slightly rounded with minimal vertical sides. Square drive is designed to reduce the risk of stripping and allow single-handed installation. Additionally reduces the ability to tamper with the fastener once installed.

  • Diameter: #8
  • Drive Size: 2R
  • Drive Type: Square
  • Finish: Powder Coated
  • Head Diameter: 0.306 - 0.322 Inch
  • Head Height: 0.105 - 0.115 Inch
  • Head Style: Pan
  • Industry Standard: ASME/ANSI B18.6.4
  • Item: Self-Tapping Sheet Metal Screw
  • Length: 1 Inch
  • Measurement: Inch
  • Point Type: Type A
  • Recess Across Flat: 0.112 Inch
  • Recess Penetration Gaging Depth: 0.060 - 0.075 Inch
  • Threads Per Inch: 15

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #8
Drive Type Square
Finish White
Head Style Pan
Length 1 Inch
Material Steel
Measurement Inch
Origin IMPORT
Point Type Type A
