Winzer

#8-18 x 1 Inch Zinc Plated Steel #2 Point Oval Head Self-Drilling Tek Screw

Item 121.11.8.1

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

Oval-head sheet metal screws are self-tapping with a rounded top and are partly countersunk with about half of the screw head above the surface. Used on thin materials like sheet metal or wood veneer their coarse threads allow them to be continually fastened and unfastened for maintenance tasks.

  • Origin: Imported
  • Zinc Plating Meets ASTM B-117 for Salt Spray Corrosion
  • Attaches metal to metal
  • Drill Capacity: 0.035 - 0.100 Inch
  • Drive Size: #2
  • Drive Type: Phillips
  • Finish: Zinc
  • Head Diameter: 0.285 - 0.312 Inch
  • Head Height: 0.152 Inch
  • Head Height Max: .100
  • Head Style: Oval
  • Industry Standard: ASME/ANSI B18.6.4 SAE J78
  • Item: Self-Drilling TEK Screw
  • Length: 1 Inch
  • Material: Steel
  • Measurement: Inch
  • Origin: Imported
  • Point Type: 3.2 mm
  • Recess Diameter: 0.186 Inch
  • Recess Penetration Gagging Depth: 0.084 - 0.108 Inch
  • Specification: ASME/ANSI B18.6.4 SAE J78 SAE J933
  • Threads Per Inch: 18

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #8
Drive Type Phillips
Finish Zinc
Head Style Oval
Length 1 Inch
Material Steel
Measurement Inch
