Winzer

Hex Washer Head 12 x 1 1/4 Tek#5 Wrg

Item 123.02.1224.114

We Stand Behind Our Products

If you are not satisfied, return within 90 days for a full refund.

Description

  • Teks Drill Point - Non walking cutting edges pigtail reduction Engages material faster drills with less effort safer installation
  • Climaseal� - Coating provides long life protection
  • Drill & Tap Capacity: 0.125 - 0.500 Inch
  • Tensile Strength: 3020 lb.
  • ICC Approved - ESR-1976 ER-3056 FM Approved - J.I. 2 X 9A2 AM
  • Diameter: #12
  • Drive Type: 0.016 Inch
  • Finish: Climaseal
  • Head Height: 0.139 - 0.155 Inch
  • Head Height Max: .155
  • Head Style: Indented Hex Washer
  • Industry Standard: ASME/ANSI B18.6.4 SAE J78
  • Item: Self-Drilling TEK Screw
  • Length: 1-1/4 Inch
  • Material: Steel
  • Measurement: Inch
  • Origin: USA
  • Point Type: #5
  • Specification: ASME/ANSI B18.6.4 SAE J78 SAE J933
  • Threads Per Inch: 24
  • Washer Diameter: 0.398 - 0.432 Inch
  • Washer Thickness: 0.022 - 0.039 Inch
  • Width Across Corner: 0.340 Inch

Photographs are representational and may not be size accurate.

Key Specifications
Diameter #12
Head Style Hex Washer
Length 1-1/4 Inch
Material Steel
Measurement Inch
Origin USA
